Build
| Frame |
Size: XS, S, Alpha Platinum Aluminium, curved top tube, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle; Size: M, L, XL, Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle Tire Clearance:Â 2.6in Colors:Â Dark Prismatic / Trek Black; White Prismatic / Plasma Grey Pearl |
|---|---|
| Fork |
SR Suntour Zeron 35, air spring, tapered steerer, oversized crown, 44 mm offset, Boost110, 15 mm bolt-on thru axle, 100 mm travel Travel:Â 100mm Spring Type:Â Air |
| Stem |
Size: XS, S, M, Bontrager Elite, 31.8 mm, Blendr light mount, 7-degree rise, 60 mm length; Size: L, XL, Bontrager Elite, 31.8 mm, Blendr light mount, 7-degree rise, 70 mm length |
| Handlebar |
Size: XS, S, Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width; Size: M, L, XL, Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
| Saddle |
Bontrager Commuter Comp |
| Seatpost |
Size: XS, S, Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length; Size: M, Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length; Size: L, XL, Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length Type:Â Rigid |
| Pedals |
VP-536 nylon platform |
| Grips |
Bontrager XR Endurance Comp, lock-on |
Groupset
| Rear Derailleur |
Shimano XT M8100, long cage |
|---|---|
| Crank |
E*thirteen E*spec Plus, 165 mm length |
| Shifters |
Shimano Deore M6100, 12-speed |
| Cassette |
Shimano Deore M6100, 10-51, 12-speed |
| Chain |
Shimano Deore M6100, 12-speed |
| Brakes |
Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper Type:Â Shimano Hydraulic Disc |
Wheels
| Rims |
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve |
|---|---|
| Front Hub |
Shimano TC500 alloy, CentreLock, 110×15 mm thru axle |
| Rear Hub |
Shimano TC500 alloy, CentreLock, 148×12 mm thru axle |
| Tires |
Size: XS, S, Bontrager LT4 Expert, reflective strip, wire bead, 60 tpi, 27.5×2.40in; Size: M, L, XL, Bontrager LT4 Expert, reflective strip, wire bead, 60 tpi, 29×2.40in |
Electric Components
| Motor |
Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm |
|---|---|
| Battery |
Bosch PowerTube 625Wh, smart system Recycling Program:Â Â Call2Recycle |
| Remote |
Bosch Intuvia 100, smart system |
| Display |
Bosch LED remote, smart system |
| Charger |
Bosch standard 4A, 230V, smart system |
Accessories
| Fenders |
Size: XS, S, Trek Powerfly 27.5in custom fender; Size: XS, S, M, L, XL, Trek Powerfly custom mudguard; Size: M, L, XL, Trek Powerfly 29in custom fender |
|---|---|
| Racks |
MIK-compatible alloy rear rack |
