2025 Kawasaki KLX 110R Specifications
| Manufacturer | Kawasaki |
| Model Year | 2025 |
| Model | KLX 110R |
| Model Code | KLX110CSFNN |
| Stock Number | 2025483 |
| Color | Lime Green |
| Brakes | Front: 90 mm mechanical drum, cable actuated Rear: 110 mm mechanical drum, rod actuated |
| Tires | Front: 2.50 x 14 Rear: 3.00 x 12 |
| Length | 61.4 in. |
| Height | 37.6 in. |
| Width | 25.6 in. |
| Weight | Curb: 167.5 lb.* *Includes all necessary fluids, fuel (90%+ capacity), and tool kit (if supplied). |
| Ground Clearance | 8.5 in. |
| Wheelbase | 42.3 in. |
| Seat Height | 26.8 in. |
| Transmission | 4-speed, return shift, automatic centrifugal clutch with wet, multi-disc clutch |
| Final Drive | Chain |
| Engine | 4-stroke, SOHC, single-cylinder |
| Cooling | Air |
| Displacement | 112 cc |
| Bore x Stroke | 2.1 x 2.0 in. (53 x 50.6 mm) |
| Compression Ratio | 9.5:1 |
| Fuel System | Keihin PB18 carburetor with throttle limiter screw on grip housing |
| Ignition | DC-CDI |
| Fuel Capacity | 1 gal. |
| Frame | Backbone, high-tensile steel |
| Front Suspension | 30 mm hydraulic telescopic fork Wheel Travel: 4.3 in. |
| Rear Suspension | Swingarm with single hydraulic shock Wheel Travel: 4.3 in. |
| Rake | 24.8° |
| Trail | 2.0 in. |
