Merida NINETY-SIX XT Bike 2025 Overview
Build
| Frame |
NINETY-SIX CF4 III, 100mm suspension travel, material: carbon, 29×2.35″ max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard BB Standard:?BSA, 73mm, Threaded |
|---|---|
| Fork |
Fox 34 Float SC Performance, Air, 120mm suspension travel, Tapered, 3 Pos Remote lockout, 44mm fork offset Travel:?120mm Spring Type:?Air |
| Shock |
Fox Float SL Performance Elite, Large Volume aircan, 3 Pos PTL remote lockout Travel:?100mm |
| Bottom Bracket |
Shimano BB-MT-501, 24mm |
| Headset |
Acros ICR MERIDA INTEGRATED neck, Upper and lower IPS sealing |
| Handlebar |
MERIDA EXPERT CC, material: aluminium, 760mm width, flat |
| Saddle |
MERIDA EXPERT SL, 6% recycled and 23% nature material, V-mount, incl. MERIDA minitool |
| Seatpost |
MERIDA TEAM TR SL, 30.9mm diameter, 0mm setback, 150mm travel seatpost Type:?Dropper |
Groupset
| Rear Derailleur |
Shimano XT M8100 Shadow+, SGS |
|---|---|
| Crank |
Shimano XT, 32 teeth, 170 mm-S, 175 mm-M up |
| Shifters |
JD-FL lever |
| Cassette |
Shimano XT, 10-51 teeth, 12 speed |
| Chain |
KMC X12 |
| Brakes |
Shimano XT M8100, 2 piston Type:?Hydraulic Disc |
Wheels
| Rims |
MERIDA EXPERT CC II, 25mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes |
Double Butted Black stainless |
| Front Hub |
Shimano XT, 110x15mm width front hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano XT, 148x12mm width rear hub, 32 spoke holes, Centerlock |
| Tires |
Maxxis Rekon Race, 29×2.4″ WT, tubeless ready, 3C MaxxTerra EXO |
| Disc Rotors |
Shimano RT54, 180mm, 160mm |
