Build
| Frame |
Canyon Grand Canyon:ON AL, Axle dimension: 12×148 mm, Material: Aluminium (AL) BB Standard:Â Bosch, Press Fit Color:Â Eis Am Steel |
|---|---|
| Fork |
FOX 34 AWL, Axle dimension: 15×110 mm, Stanchion Diameter: 34 mm, Travel: 120 mm, Fork steer tube diameter: 1 1/8″ – 1,5″, Offset: 51 mm, Weight: 1.56 kg Travel:Â 120mm Spring Type:Â Air |
| Bottom Bracket |
Bosch, press-fit |
| Stem |
Canyon:ON ST0031, Canyon E-MTB stem., Length: 45 mm, Fork steer tube diameter: 1 1/8″, Clamping diameter: 35,0 mm |
| Handlebar |
Canyon:ON HB0056 Riser bar, Aluminum., Clamping diameter: 35,0 mm, Width: 760 mm, Rise: 20 mm |
| Saddle |
Fizik Terra Alpaca X5, Weight: 230 g |
| Seatpost |
Iridium Dropper Post, Move more freely on steep descents, by dropping down saddle with the press of a handlebar-mounted button. With internal cabling., Clamp diameter: 30,9 mm, Material: Aluminium (AL), Weight: 567 g Type:Â Dropper |
| Pedals |
Iridium VP-536 |
| Grips |
Canyon Lock-On Grips |
Groupset
| Rear Derailleur |
Shimano Deore XT M8100, Cage length: long, Weight: 286 g |
|---|---|
| Crank |
FSA 745 E-Bike Crank for Bosch Gen4 |
| Shifters |
Shimano Deore M6100 12s, Weight: 139 g |
| Cassette |
Shimano Deore M6100, Number of sprockets: 12, Range: 10-51 12S |
| Chain |
Shimano CN-M6100 |
| Chain Guide |
Canyon GP0432-01 Chain Guide |
| Brakes |
Magura CTE ABS, Number of pistons: 4 Type:Â Hydraulic Disc |
Wheels
| Rims |
Rodi Tryp 30 12×148, Rotor mount: IS 6-bolt, Weight: 1.16 kg | Rodi Tryp 30 15×110, Rotor mount: IS 6-bolt, Weight: 1.09 kg |
|---|---|
| Tires |
Schwalbe Nobby Nic Performance, 2.6, Width: 2.6″ |
| Disc Rotors |
Magura MDR-C, Size: 203 mm, Weight: 183 g | Magura ABS sensor ring R70, Size: 203 mm, Weight: 41 g |
Electric Components
| Motor |
Bosch Performance Line CX |
|---|---|
| Battery |
Bosch PowerTube 750Wh |
| Charger |
Bosch 4A |
