Build
| Frame |
Canyon Spectral:ONfly CF, Axle dimension: 12×148 mm, Material: Carbon (CF), Weight: 2.70 kg Hanger Standard:Â UDH Color:Â Dark Matter |
|---|---|
| Fork |
FOX 36 Factory Grip2, Axle dimension: 15×110 mm, Stanchion Diameter: 40 mm, Travel: 160 mm, Fork steer tube diameter: 1 1/8″ – 1,5″, Offset: 44 mm, Weight: 2.18 kg Travel:Â 160mm Spring Type:Â Air |
| Shock |
Fox Float x Factory 230×60 mm, Weight: 499 g Travel:Â 150mm |
| Stem |
Canyon:ON ST0031, Canyon E-MTB stem., Length: 45 mm, Fork steer tube diameter: 1 1/8″, Clamping diameter: 35,0 mm |
| Handlebar |
Canyon:ON HB0057 Riser bar, Canyon-developed E-MTB handlebar for top control levels on the trail., Clamping diameter: 35,0 mm, Width: 780 mm, Rise: 30 mm |
| Saddle |
Fizik Terra Aidon X5, Gender: Unisex, Weight: 251 g |
| Seatpost |
Canyon SP0070-01, Air cartridge. Cable actuated., Travel: Dependent on frame size (see component geometry table.), Clamp diameter: 34,9 mm, Material: Aluminium (AL), Weight: 34 g Type:Â Dropper |
| Pedals |
Iridium VP-536 |
| Grips |
Canyon Lock-On |
Groupset
| Rear Derailleur |
SRAM XX Eagle AXS Transmission, Weight: 450 g |
|---|---|
| Crank |
SRAM XX Eagle E-MTB Crank |
| Shifters |
SRAM AXS POD Ultimate, Weight: 71 g |
| Cassette |
SRAM XX Eagle Transmission 10-52, Number of sprockets: 12 |
| Chain |
SRAM XX T-Type |
| Chain Guide |
Canyon GP0480-01 Chain Guide |
| Brakes |
SRAM Code Ultimate Stealth Type:Â Hydraulic Disc |
Wheels
| Rims |
Reynolds Trail 329 Blacklabel Expert, Axle dimension: 15×110 mm, Rotor mount: Center Lock, Rim material: Carbon, Weight: 712 g | Reynolds Blacklabel 327 Trail Expert, Axle dimension: 12×148 mm, Rotor mount: Center Lock, Weight: 864 g |
|---|---|
| Tires |
Maxxis Minion DHR II Exo, Width: 2,4″, Weight: 1.03 kg | Maxxis Minion DHR II 3C MaxxTerra EXO+ 2,4×27,5″, Width: 2.4″, Weight: 1.00 kg |
| Disc Rotors |
SRAM HS2, Size: 200 mm, Weight: 300 g |
Electric Components
| Motor |
TQ HPR 50 Motor |
|---|---|
| Battery |
SRAM Powerpack | TQ HPR Battery |
