Build
| Frame |
SMOOTHWALL Carbon | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-4 Adjustable Geometry + Suspension Rate | 140mm Travel. SMOOTHWALL Carbon Rear Triangle Colors: Yellow / Brown; Black / Grey/beige |
|---|---|
| Fork |
RockShox Lyrik Select 150mm | Charger RC Damper | 29 = 42mm Offset Travel: 150mm Spring Type: Air |
| Shock |
RockShox Deluxe Select+ | Sealed Bearing Eyelet | 20x8mm F Hardware | All Sizes = 210x55mm | Size-Specific tune in FAQ Travel: 140mm |
| Bottom Bracket |
Shimano SM-BBMT500 |
| Headset |
FSA Orbit NO.57E ZS44|56 | Sealed 36×45 Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5in Crown Race |
| Stem |
Rocky Mountain 31.8 AM | 5 Rise | All Sizes = 40mm |
| Handlebar |
Rocky Mountain AM | 780mm Width | 25mm Rise | 9 Backsweep | 5 Upsweep | 31.8 Clamp |
| Saddle |
WTB Volt Race 142 |
| Seatpost |
X Fusion Manic Composite 30.9mm | SM = 125mm | MD = 150mm | LG = 170mm | XL = 200mm Type: Dropper |
| Grips |
Rocky Mountain Lock On Light |
Groupset
| Rear Derailleur |
Shimano XT |
|---|---|
| Crank |
Race Face Ride Cinch 34T | 24mm Spindle | Crank Length: SM – MD = 165mm | LG – XL = 170mm |
| Shifters |
Shimano SLX |
| Cassette |
SunRace CSMZ603 WA1 11-51T |
| Chain |
KMC X12-1 |
| Brakes |
Shimano MT6120 4 Piston | Resin Pads Type: Hydraulic Disc |
Wheels
| Rims |
WTB ST Light i30 TCS 2.0 Tubeless | 32H / Tubeless Ready – Tape / Valves Incl |
|---|---|
| Spokes |
2.0 Stainless |
| Front Hub |
Shimano TC500 | 15x110m |
| Rear Hub |
Shimano TC500 Boost 148mm |
| Tires |
F: Maxxis Minion DHF 2.5 WT EXO Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready // |
Electric Components
| Motor |
Dyname 4.0 Mountain Bike Drive | 700W Max Power | 250W Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM – High Efficiency class 1 eMTB System | Designed in Canada |
|---|---|
| Battery |
720 Wh Removable Integrated Li-Ion | 100% Charged in 3:55 (4A) / 7:35 (2A) | 80% Charged in 2:55 (4A) / 6:05 (2A) Recycling Program: Call2Recycle |
| Remote |
Rocky Mountain Micro Remote |
| Display |
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration |
| Charger |
Rocky Mountain Powerplay FAST Charger V1 | 4A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4) |
