Build
| Frame |
Size: XS, S, Alpha Platinum Aluminium, curved top tube, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle; Size: M, L, XL, Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle BB Standard:Â Bosch, Press Fit Tire Clearance:Â 2.6in Colors:Â Dark Aquatic / Black; Grey Pearl / Lithium Grey; Grey / Purple Flip |
|---|---|
| Fork |
Size: XS, SR Suntour XCM 34, coil spring, preload, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm thru axle, 80 mm travel; Size: S, M, L, XL, SR Suntour XCM 34, coil spring, preload, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm thru axle, 120 mm travel Travel:Â 120mm Spring Type:Â Coil |
| Bottom Bracket |
Bosch, press-fit |
| Stem |
Size: XS, Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length; Size: S, M, Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length; Size: L, XL, Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length |
| Handlebar |
Size: XS, S, Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width; Size: M, L, XL, Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
| Saddle |
Bontrager Commuter Comp |
| Seatpost |
Size: XS, S, Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length; Size: M, Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length; Size: L, XL, Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length Type:Â Rigid |
| Pedals |
VP-536 nylon platform |
| Grips |
Bontrager XR Endurance Comp, lock-on |
Groupset
| Rear Derailleur |
Shimano CUES U4000 |
|---|---|
| Crank |
FSA Bosch CK-220, 36T ring, 165 mm length |
| Shifters |
Shimano U4000, 9-speed |
| Cassette |
Shimano LINKGLIDE LG300, 11-46, 9-speed |
| Chain |
Shimano LG500, 9/10/11-speed |
| Brakes |
Tektro HD-M275 hydraulic disc Type:Â Tektro Hydraulic Disc |
Wheels
| Rims |
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve |
|---|---|
| Front Hub |
Shimano TC500 alloy, CentreLock, 110×15 mm thru axle |
| Rear Hub |
Shimano TC500 alloy, CentreLock, 148×12 mm thru axle |
| Tires |
Size: XS, S, Bontrager XR3 Comp, wire bead, 30 tpi, 27.5×2.35in; Size: M, L, XL, Bontrager XR3 Comp, wire bead, 30 tpi, 29×2.30in |
| Disc Rotors |
Tektro, CentreLock, 203 mm |
Electric Components
| Motor |
Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm |
|---|---|
| Battery |
Bosch PowerTube 625Wh, smart system Recycling Program:Â Â Call2Recycle |
| Remote |
Bosch Intuvia 100, smart system |
| Display |
Bosch LED remote, smart system |
| Charger |
Bosch standard 2A, 230V, smart system |
