Build
Frame |
Alpha Smooth Aluminium, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc, 135×5 mm QR |
---|---|
Fork |
SR Suntour Mobie 34, air spring, rebound and compression adjust, tapered alloy steerer, 100×15 mm thru axle, 60 mm travel Travel:Â 60mm Spring Type:Â Air |
Stem |
Size: M, adjustable aluminium, 31.8 mm, 90 mm length,; Size: L, XL, Alloy adjustable stem, 110 mm length |
Handlebar |
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width |
Saddle |
Selle Royal ON relaxed |
Seatpost |
Ergotec PM705-N suspension Type:Â Suspension |
Pedals |
Bontrager City pedals |
Grips |
Bontrager Satellite Elite, alloy lock-on |
Groupset
Rear Derailleur |
Shimano CUES U6000 GS |
---|---|
Crank |
Size: M, ProWheel alloy, 170 mm length; Size: L, XL, ProWheel alloy, 175 mm length |
Shifters |
Shimano CUES U6000 w/optical gear display, 10-speed |
Cassette |
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed |
Chain |
Shimano LG500, 9/10/11-speed |
Brakes |
Size: M, L, XL, Shimano MT401 / MT420 hydraulic disc, 180 mm rotor; Size: M, L, XL, Shimano MT401 / MT420 hydraulic disc Type:Â Shimano Hydraulic Disc |
Wheels
Rims |
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve |
---|---|
Front Hub |
Bontrager sealed bearing, 32-hole, 15 mm alloy thru-axle |
Rear Hub |
Formula CL-52 alloy, 135×5 mm QR |
Tires |
Schwalbe Super Moto-X, reflective, wire bead, GreenGuard protection, 650×62 mm |
Disc Rotors |
Size: M, L, XL, Shimano RT30, CentreLock, 180 mm; Size: M, L, XL, Shimano EM300, CentreLock, 180 mm |
Electric Components
Motor |
Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe) |
---|---|
Remote |
Bosch Kiox 500, smart system |
Display |
Bosch LED remote, smart system |
Charger |
Bosch standard 4A, 230V, smart system |
Accessories
Lights |
Size: M, L, XL, Spanninga SOLO for e-bike; Size: M, L, XL, Herrmans H-Black MR9-E, 60 lux, LED, headlight |
---|---|
Fenders |
Size: M, L, XL, SKS plastic, rear; Size: M, L, XL, SKS plastic, front |
Racks |
Alloy rear rack, 25 kg max weight |
