2023 Trek Top Fuel 9.7 A 27.5″ / 29″ carbon frame full suspension trail bike with upper mid-range components.
Build
| Frame | carbon frame BB Standard: BSA, 73mm, Threaded Tire Clearance: 2.5″ Colors: Matte Raw Carbon; Blue Smoke / Alpine/quicksilver Fade; Hex Blue |
|---|---|
| Fork | Fox Rhythm 34, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 120mm travel |
| Rear Shock | Fox Performance Float DPS, 3-position damper, 185mm x 50mm |
| Bottom Bracket | Size: XS, S, M, M/L, L, XL, Shimano BB-MT501 BSA; Size: XS, S, M, M/L, L, XL, Shimano SM-BB52, 73mm, threaded external bearing |
| Headset | Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8” top, 1.5” bottom |
| Stem | Bontrager Elite, 35mm, 0 degree, 45mm length |
| Handlebar | Size: XS, S, Bontrager Line, alloy, 35mm, 27.5mm rise, 750mm width; Size: M, M/L, L, XL, Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width |
| Saddle | Bontrager Arvada, steel rails, 138mm width |
| Seatpost | Size: XS, S, TranzX JD-YSP39, 100mm travel, internal routing, 34.9mm; Size: M, M/L, TranzX JD-YSP39, 150mm travel, internal routing, 34.9mm; Size: L, XL, TranzX JD-YSP39, 170mm travel, internal routing, 34.9mm |
| Grips | Bontrager XR Trail Comp, nylon lock-on |
Groupset
| Rear Derailleur | Shimano XT M8100, long cage |
|---|---|
| Crank | Size: XS, S, M, M/L, L, Shimano Deore M6120, 30T ring, 55mm chainline, 170mm length; Size: XL, Shimano Deore M6120, 30T ring, 55mm chainline, 175mm length |
| Shifters | Shimano XT M8100, 12 speed |
| Cassette | Shimano SLX M7100, 10-51, 12 speed |
| Chain | Shimano SLX M7100, 12 speed |
| Brakes | Shimano 4-piston hydraulic disc, M6100 lever, M6120 caliper |
Wheels
| Rims | Front: Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, Rear: Size: XS, Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 54, 6-bolt, Boost148, 12mm thru axle; Size: S, M, M/L, L, XL, Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle |
|---|---|
| Front Hub | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
| Rear Hub | Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12 mm thru axle |
| Tires | Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120tpi, 29.x2.40” |
| Disk Rotors | Size: XS, S, M, M/L, L, XL, Shimano RT66, 6-bolt, 160mm; Size: XS, S, M, M/L, L, XL, Shimano RT66, 6-bolt, 180mm |
