2022 Trek X-Caliber 9 A 27.5″ / 29″ aluminum frame hardtail crosscountry bike with upper mid-range components.
Build
| Frame |
aluminum frame BB Standard:Â BSA, 73mm, Threaded Tire Clearance:Â 2.8″ Color:Â Alpine Blue |
|---|---|
| Fork |
Size: S, RockShox Recon Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 37mm offset, Boost110, 15mm Maxle Stealth, 100mm travel; Size: M, ML, L, XL, XXL, RockShox Recon Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 100mm travel |
| Bottom Bracket |
Shimano SM-BB52, 73mm, threaded external bearing |
| Headset |
Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8” top, 1.5” bottom |
| Stem |
Size: S, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm length; Size: M, ML, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: L, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: XL, XXL, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length |
| Handlebar |
Size: S, M, Bontrager alloy, 31.8mm, 5mm rise, 720mm width; Size: ML, L, XL, XXL, Bontrager alloy, 31.8mm, 15mm rise, 750mm width |
| Saddle |
Bontrager Arvada, steel rails, 138mm width |
| Seatpost |
Size: S, M, TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length; Size: ML, L, XL, XXL, TranzX JD-YSP18, 130mm travel, internal routing, 31.6mm, 425mm length |
| Grips |
Bontrager XR Trail Comp, nylon lock-on |
Groupset
| Rear Derailleur |
Shimano XT M8100, long cage |
|---|---|
| Crank |
Size: S, M, Shimano MT611, 30T steel ring, alloy spider, 52mm chainline, 170mm length; Size: ML, L, XL, XXL, Shimano MT611, 30T steel ring, alloy spider, 52mm chainline, 175mm length |
| Shifters |
Shimano SLX M7100, 12 speed |
| Cassette |
Shimano SLX M7100, 10-51, 12 speed |
| Chain |
Shimano SLX M7100, 12 speed |
| Brakes |
Shimano hydraulic disc, MT4100 lever, MT410 caliper |
Wheels
| Rims |
Size: S, Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, presta valve; Size: S, Bontrager Kovee, double-wall, Tubeless Ready, 32-hole, 23mm width, presta valve; Size: M, ML, L, XL, XXL, Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, Presta valve; Size: M, ML, L, XL, XXL, Bontrager Kovee, double-wall, Tubeless Ready, 32-hole, 23mm width, Presta valve |
|---|---|
| Front Hub |
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle |
| Rear Hub |
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost141, 5mm QR |
| Tires |
Size: S, Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 27.5×2.35”; Size: M, ML, L, XL, XXL, Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 29×2.35” |
| Disk Rotors |
Size: S, M, ML, L, XL, XXL, Shimano RT56, 6-bolt, 180mm; Size: S, M, ML, L, XL, XXL, Shimano RT56, 6-bolt, 160mm |
